Energies
Brand Name: NJouka
DIY Supplies: Plumbing
Model Number: TUF-2000M
Measurement Range: 15-100mm
TS2: 15-100mm
TUF-2000M TS-2Digital Ultrasonic Flowmeter Flow Meter Ultrasinic Flow Module/RTU with TS2 transducer (DN15-100mm) -30 ~ +90C
|
Features |
Description |
|
High accuracy |
Linearity: better than 0.5%, Repeatability: better than 0.2%, Accuracy: better than +-1% |
|
Wide measuring range |
Several types transducer for selection, pipe size from DN15mm to DN6000mm |
|
Far transmission distance |
Connecting module and secondary meter through RS-485 interface, transmission distance up to 1000m |
|
Powerful Functions |
Current output: 4-20mA, one channel, can be used for flow/heat transmitter; OCT output: two channels, can be used for flow /heat switch; Current input: 4-20mA, three channels, can be used for data collector; Tri-wire resistance signal input (PT100): two channels, can be used for calorimeter. |
|
Wide Application |
Its unique features, particularly low cost, small size, high performance, local display, make it the ideal choice for industrial automation, processing control, flow meter networking, composing multi-channel, high accuracy flow meter. |
Structure of Unified Calorimeter:
Standard Packing List:
- Transmitter 1 set
- TM-1 type transducer 1 pair
- Clamp Fixture 1 set
- 5m×2 Transducer Cable 1 pair
- English User Manual 1 piece (electronic
Turn Power into
Knowledge
Track energy use in real time! The Vue Energy Monitor doesn't guess what appliances you have. It's connected directly to the circuits you care about, like your furnace, A/C, refrigerator, or solar generation. It monitors them 24/7. You can also add Emporia Smart Plugs to monitor the smaller things you care about. You'll know exactly how much energy you're using or generating in real time and historically by the minute, hour, day, week, month, and year.
Peace of Mind
The Gen 2 Vue Energy Monitor keeps tabs on your energy use 24 hours a day. The Emporia App has valuable alerts that protect your family and your home. Set alerts for times when you approach monthly peak energy use, when you leave lights or an oven on, when things like sump pumps don't turn off or on, and when when your A/C uses more energy than it should. Download the App.
Save Money
The Gen 2 Vue keeps track of the energy used in your home to help you identify appliances and circuits that waste energy and increase monthly bills. The Emporia App suggests valuable savings opportunities and also allows you to set alerts to keep you notified when appliances and lights have been left on.
Generating Energy?
The Emporia Gen 2 Vue monitors renewable energy net metering out of the box, giving you clear measurements of how much energy is being returned to the grid (and saving you money). With the 50A sensors, you can also monitor your energy generation in real time and historically by the minute, hour, day, week, month, and year.
How the Gen 2 Vue Works
Install in Panel
The Vue Installs in most homes in the electrical panel. Systems that only have access to busbars will require our Flexible Current Sensors. The Vue monitors renewable energy net metering with no extra equipment to buy. The Vue is UL and CE Listed for your safety.
Monitor Circuits
Add 50A sensor bundles to gain the ability to monitor up to 16 individual circuits. You can buy the sensors bundled with the Vue or separately, if you already own a Vue. This allows you to monitor important appliances and equipment, like your air conditioner, furnace, water heater, washer/dryer, solar generation, and more.
Connect over WiFi
- Connects to Emporia over 2.4GHz WiFi
- Monitors electricity use/generation 24/7
- Collects granular, 1-second energy data
- Monitors voltage for real power metrics
- Tracks how much energy is being used by important appliances and equipment or how much is generated and sent back to the grid
Manage Your Energy
- Manage energy use and generation with a simple iOS or Android app
- Receive actionable recommendations
- Get real-time data anywhere, anytime
- Prevent costly repairs
- Conserve Energy
- Save Money
Ready for a Gen 2 Vue?
Take Control of Your Energy
- Track your energy usage.
- Get savings opportunities.
- Receive energy saving notifications.
- Make your home more energy efficient.
-
Plus d'informations
Emporia has developed the next generation of the Vue Energy Monitor. Committed to bringing the best value at the lowest price possible, the Vue provides everything you need to monitor your entire home's energy usage in real time, as well as 16 extra sensors to allow you to monitor individual circuits. Not only can you see how much energy your home is using at any moment and over time, but you can also monitor how your individual appliances affect your energy bills.
- READY FOR 3-PHASE: Includes an extra 200A Sensor for light commercial 3-phase/4-wire electrical systems (up to 415Y/240VAC & less than 600A ). Does not work with 3-phase/3-wire systems (Delta systems with no neutral). NO NEED TO PURCHASE AN EXTRA SENSOR
- INSTALLS IN CIRCUIT PANEL of most homes with clamp-on sensors; although it doesn't typically work in panels with access only to busbars. INSPECT YOUR ELECTRICAL PANEL for compatibility. Includes DIY instructions, though a professional electrician is recommended.
- 24/7 ENERGY MONITORING: Monitor your home's real power anywhere, anytime to prevent costly repairs, conserve energy, and save costs. Monitor solar / net metering. PROTECTED BY A 1-YEAR WARRANTY.
- LOWER YOUR ELECTRIC BILL: Gauge real-time spending and get actionable notifications to understand where you can save costs.
- REAL-TIME ENERGY DATA: REQUIRES 2.4 GHz WIFI WITH AN INTERNET CONNECTION to monitor energy use with iPhone / Android app. Vue sensors provide 1-second data and are accurate from ±2%. The Vue is UL and CE Listed for your safety. 1 second data is retained 3 hours, 1 minute data is retained 7 days, 1 hour data is retained indefinitely. Export the data whenever you want in the app.
APPLIANCE MONITORING WITHOUT GUESSWORK: Comes with sixteen 50A sensors to accurately monitor your air conditioner, furnace, water heater, washer, dryer, range, etc.
- Bundle includes:
- Gen 2 Vue Energy Monitor
- 2 or Three 200A current sensors for service mains
- 0/8/16x 50A current sensors for individual circuits
- Wire harness
- Extra wire & wire nuts
- Wifi antenna & cable
- Power the Vue directly from a 15A or 20A breaker
- Professional installation recommended
- Granular 1-second data interval
- Each sensor is accurate from ±1%
- Operates regardless of your utility
- Comes with sixteen 50A sensors to monitor individual circuits
- Interact with your Emporia Vue through your mobile device
- Real-time monitoring of your energy usage and production with helpful units and measurements
- Actionable notifications will help you:
- Conserve energy
- Lower carbon emissions
- Increase grid reliability
- Generate energy savings
- Shift usage patterns from peak to off-peak
- Get clear calculations that show your savings when you perform actions recommended by the Emporia Vue
Vue energy monitor dimensions:
- 4.1" x 3.1" x 1.1" (105mm x 80mm x 30mm)
200A sensor dimensions:
- 2.6" x 1.7" x 1.6" (65mm x 44mm x 41mm)
- Window diameter: 1" (26mm)
- Cable length: 39" (1m)
- Connector plug: 3.5mm
50A sensor dimensions:
- 1.6" x 0.9" x 1" (41mm x 23mm x 26mm)
- Window diameter: 0.39" (10mm)
- Cable length: 39" (1m)
- Connector plug: 2.5mm
