HF9624 4G PLC Remote Control Element Supports Mitsubishi, Siemens, Omron, Schneider, Panasonic...
Rated 3.5/5 based on 11 customer reviews

HF9624 4G PLC Remote Control Element Supports Mitsubishi, Siemens, Omron, Schneider, Panasonic...

Voir tous les produits de : MultiShop.lu
Disponibilité : En stock
€153,74 €164,72
Color

SPECIFICATIONS

Brand Name: HF HIGH-FLYING

Type: Cable Adapter

Package: Yes

Products Status: STOCK

Model Number: HF9624

Processor: MIPS

Basic Frequency: 580MHz

Operating System: Linux OpenWrt

Internet Type: 4G/3G/GSM/GPRS

Size: 178mm x 95mm x 26mm

Operating Temp.: -25 ~ 85°C HF9624

Input Voltage: 9~36VDC 4G PLC Remote Control Element

Supports PLC Brand: Mitsubishi, Siemens, Omron, Schneider, Panasonic,Xinjie...

HF9624 Overview of Characteristic Supports Mitsubishi, Siemens, Omron, Schneider, Panasonic, Xinjie...

MIPS MCU with 16MB Flash and 64MB SRAM. Run with Linux OpenWrt Support 4G/3G/GPRS, FDD-LTE, TDD-LTE, WCDMA, TD-SCDMA, CDMA2000, CDMA 1X/EVDO, GSM900/1800 Support Virtual COM, Virtual Path Connect to PLC for Remote Monitor Two RS232/RS485/RS422 interface to 4G/3G/2G Two Ethernet to 4G/3G/GPRS Support 802.11bgn Wi-Fi to 4G/3G/GPRS Support APN network Support VPN(PPTP, L2TP, L2TP+IPSEC) Support TCP/IP/Telnet/Modbus TCP Protocol, support TLS/AES/DES3 enrtyption Support Router or Bridge Network Working Mode. Support 10/100M Ethernet Auto-Negotiation Support Easy Configuration Through a Web Interface or PC IOTService Tool locally or remotely Support IOTBridge Management Support Web OTA Wirelss Upgrade Support Wide DC Input 9~36VDC Size: 178mm x 95mm x 26mm

HF9624 General Description

The 4G serial server device HF9624 provides protocol conversion among RS232/RS485/RS422 interface, Ethernet/Wi-Fi and 3G/4G,which can meet the solutions for serial/network transmission of industrial products. The HF9624 integrates 4G/3G,Wi-Fi, Ethernet, high-speed serial port, RS232/RS485/RS422 interfaces, and it is based on Ecos operation system and contain webpage, TCP/IP stack. It supports remote monitor PLC products of different brand.
